U.S. Type
American wide-bodied shackle
High strength bow type (C) shackle (American standard shackle)
Material: alloy steel integral forged
Safety factor: 1t-25t: 6 More than 25t: 4
A type: Internal thread type
B type: Outside nut type
BOCHI High Quality Shackles: Light weight, small volume, high safety coefficient, it is easy to operate.
SWL(t) | (in.) | Dimension (mm) | Weight | |||||
d | A | B | C | H | (kg) | |||
1 | 3/8 | 10 | 12 | 16 | 26 | 36 | 0.2 | |
2 | 1/2 | 13 | 16 | 21 | 33 | 46.5 | 0.43 | |
3.25 | 5/8 | 16 | 20 | 27 | 42 | 58 | 0.83 | |
4.75 | 3/4 | 19 | 22 | 32 | 51 | 69.5 | 1.3 | |
6.5 | 7/8 | 22 | 25 | 37 | 58 | 82.5 | 1.8 | |
8.5 | 1 | 25 | 30 | 43 | 68 | 92.5 | 2.8 | |
9.5 | 1-1/8 | 29 | 32 | 46 | 74 | 106.5 | 3.85 | |
12 | 1-1/4 | 32 | 36 | 52 | 83 | 117 | 5.3 | |
13.5 | 1-3/8 | 35 | 38 | 57 | 89 | 133 | 6.7 | |
17 | 1-1/2 | 38 | 42 | 60 | 98 | 146 | 8.8 | |
25 | 1-3/4 | 44 | 50 | 73 | 127 | 175 | 14.6 | |
35 | 2 | 51 | 56 | 83 | 146 | 195 | 22 | |
45 | 2-1/4 | 56 | 65 | 95 | 160 | 233 | 31 | |
55 | 2-1/2 | 64 | 70 | 105 | 184 | 266 | 43.3 | |
60 | 2-3/4 | 70 | 78 | 100 | 200 | 289 | 57 | |
85(80) | 3 | 76 | 82 | 121 | 229 | 335 | 73 | |
100 | 3-3/8 | 86 | 92 | 131 | 232 | 356 | 100 | |
120 | 3-1/2 | 90 | 95 | 154 | 241 | 372 | 114 | |
150 | 4 | 102 | 108 | 160 | 254 | 368 | 165 | |
175 | 4-1/4 | 108 | 120 | 160 | 254 | 368 | 190 | |
200 | 4-3/4 | 120 | 130 | 184 | 280 | 396 | 283 | |
250 | 5 | 127 | 140 | 210 | 330 | 470 | 350 | |
300 | 6 | 152 | 170 | 220 | 345 | 520 | 470 | |
400 | 7 | 178 | 190 | 230 | 360 | 572 | 670 |
High strength straight type (D) shackle (American standard shackle)
Material: alloy steel integral forged
Safety factor: 1t-25t: 6 More than 25t: 4
A type: Internal thread type
B type: Outside nut type
BOCHI High Quality Shackles: Light weight, small volume, high safety coefficient, it is easy to operate.
SWL(t) | (in.) | Dimension (mm) | Weight | |||
d | A | B | H | (kg) | ||
1 | 3/8 | 10 | 12 | 16 | 32 | 0.15 |
2 | 1/2 | 13 | 16 | 21 | 41 | 0.35 |
3.25 | 5/8 | 16 | 20 | 27 | 51 | 0.66 |
4.75 | 3/4 | 19 | 22 | 32 | 60 | 1 |
6.5 | 7/8 | 22 | 25 | 37 | 70.5 | 1.5 |
8.5 | 1 | 25 | 30 | 43 | 81 | 2.4 |
9.5 | 1-1/8 | 29 | 32 | 46 | 90 | 3.2 |
12 | 1-1/4 | 32 | 36 | 52 | 100 | 4.5 |
13.5 | 1-3/8 | 35 | 38 | 57 | 112 | 5.1 |
17 | 1-1/2 | 38 | 42 | 60 | 122 | 8.1 |
25 | 1-3/4 | 44 | 50 | 73 | 146 | 12.2 |
35 | 2 | 51 | 56 | 83 | 171 | 18.2 |
45 | 2-1/4 | 56 | 65 | 95 | 180 | 26 |
55 | 2-1/2 | 64 | 70 | 105 | 205 | 35.4 |
60 | 2-3/4 | 70 | 78 | 100 | 233 | 44 |
85(80) | 3 | 76 | 82 | 121 | 263 | 60.6 |
100 | 3-3/8 | 86 | 92 | 131 | 298 | 82.6 |
120 | 3-1/2 | 90 | 95 | 154 | 312 | 100 |
150 | 4 | 102 | 108 | 160 | 368 | 142 |
175 | 4-1/4 | 108 | 120 | 170 | 390 | 170 |
200 | 4-3/4 | 120 | 130 | 184 | 420 | 255 |
250 | 5 | 127 | 140 | 210 | 450 | 310 |
300 | 6 | 152 | 170 | 220 | 480 | 440 |
400 | 7 | 178 | 190 | 230 | 500 | 620 |
