45° Elbow
Technology & Parameters:
| Model | Nominal Diameter | Outside Diameter at Bevel | Center to End | ||
| 45°Elbow | |||||
| B | |||||
| DN | NPS | Series A | Series B | Long Radius | |
| BMMAETEEL001 | 15 | 0.50 | 21 1/2 | 18 | 16 |
| BMMAETEEL002 | 20 | 0.75 | 26.9 | 25 | 19 |
| BMMAETEEL003 | 25 | 1 | 33.7 | 32 | 22 |
| BMMAETEEL004 | 32 | 1.1/4 | 42.4 | 38 | 25 |
| BMMAETEEL005 | 40 | 1.1/2 | 48.3 | 45 | 29 |
| BMMAETEEL006 | 50 | 2 | 60.3 | 57 | 35 |
| BMMAETEEL007 | 65 | 2.1/2 | 76.1(73) | 76 | 44 |
| BMMAETEEL008 | 80 | 3 | 88.9 | 89 | 51 |
| BMMAETEEL009 | 90 | 3.1/2 | 101.6 | - | 57 |
| BMMAETEEL010 | 100 | 4 | 114.3 | 108 | 64 |
| BMMAETEEL011 | 125 | 5 | 139.7 | 133 | 79 |
| BMMAETEEL012 | 150 | 6 | 168.3 | 159 | 95 |
| BMMAETEEL013 | 200 | 8 | 219.1 | 219 | 127 |
| BMMAETEEL014 | 250 | 10 | 273 | 273 | 159 |
| BMMAETEEL015 | 300 | 12 | 323.9 | 325 | 190 |
| BMMAETEEL016 | 350 | 14 | 355.6 | 377 | 222 |
| BMMAETEEL017 | 400 | 16 | 406.4 | 426 | 254 |
| BMMAETEEL018 | 450 | 18 | 457.2 | 478 | 286 |
| BMMAETEEL019 | 500 | 20 | 508 | 529 | 318 |
| BMMAETEEL020 | 550 | 22 | 559 | - | 343 |
| BMMAETEEL021 | 600 | 24 | 610 | 630 | 381 |
| BMMAETEEL022 | 650 | 26 | 660 | - | 406 |
| BMMAETEEL023 | 700 | 28 | 711 | 720 | 438 |
| BMMAETEEL024 | 750 | 30 | 762 | - | 470 |
| BMMAETEEL025 | 800 | 32 | 813 | 820 | 502 |
| BMMAETEEL026 | 850 | 34 | 864 | - | 533 |
| BMMAETEEL027 | 900 | 36 | 914 | 920 | 565 |
| BMMAETEEL028 | 950 | 38 | 965 | - | 600 |
| BMMAETEEL029 | 1000 | 40 | 1016 | 1020 | 632 |
| BMMAETEEL030 | 1050 | 42 | 1067 | - | 660 |
| BMMAETEEL031 | 1100 | 44 | 1118 | 1120 | 695 |
| BMMAETEEL032 | 1150 | 46 | 1168 | - | 727 |
| BMMAETEEL033 | 1200 | 48 | 1220 | 1220 | 759 |
