Type:Area Type Controller
Name:12Lines Dual Display Fire Alarm Controller(Flush Bonding)
Main Power Supply:AC220V +10%, -15% 50Hz
Secondary Power Supply:DC24V +30%, -25%
Function:Chinese LCD, with Chinese repeater.VDR connector, recordable and inquiry fire alarm information, fault information, each line can be connected 20 detectors (not containing hand alarm button). Automatic uninterrupted conversion between alternating current power supply and direct current power supply.
Power dissipation:Monitor state<5W,alarm state<20W
Capability:12lines
Controlled Output:immediately ,delay
Touch Spot Capability:DC24V/10A
Opening Size:222×165(mm)
Outside Dimensions:252×190×110(mm)
Mounting Dimensions:237×178(mm)
Weight:3Kg
