Controllable Pitch Propeller SG Series



Technology & Parameters:

Product No. Type Hub Dia. a b c d e Vmin
BMMPP-CPP SG001 SGCP-330 330 251 132 67 312 65 240
BMMPP-CPP SG002 SGCP-390 390 289 155 77 366 65 260
BMMPP-CPP SG003 SGCP-460 460 335 183 89 420 65 285
BMMPP-CPP SG004 SGCP-505 505 373 201 95 470 65 305
BMMPP-CPP SG005 SGCP-550 550 402 219 100 506 65 320
BMMPP-CPP SG006 SGCP-600 600 432 238 107 546 65 335
BMMPP-CPP SG007 SGCP-650 650 467 258 114 586 65 365
BMMPP-CPP SG008 SGCP-650B 650 467 258 114 586 100 365
BMMPP-CPP SG009 SGCP-710 710 506 280 120 636 100 385
BMMPP-CPP SG010 SGCP-775 775 550 304 135 690 100 405
BMMPP-CPP SG011 SGCP-845 845 574 332 143 745 100 410
BMMPP-CPP SG012 SGCP-920 920 861 361 154 824 100 435
BMMPP-CPP SG013 SGCP-1000 1000 674 392 162 884 115 460
BMMPP-CPP SG014 SGCP-1095 1095 735 427 182 963 115 490
BMMPP-CPP SG015 SGCP-1190 1190 798 465 194 1052 115 525
BMMPP-CPP SG016 SGCP-1300 1300 859 508 207 1137 130 575
BMMPP-CPP SG017 SGCP-1415 1415 933 551 283 1229 130 610
BMMPP-CPP SG018 SGCP-1540 1540 1016 600 300 1332 130 655

*SG type controllable pitch propeller is servomotor in shaft,oil supply unit in front of gearbox.
*Our controllable-pitch propellers are propulsion systems that can be used with almost any type of vessel. The power spectrum ranges from 600 kW to 10,000 kW, with propeller sizes varying between approxima -tely 1.5 to 5.0 metres.
*Advanced calculation methods allow the controllable-pitch propeller systems to be optimally adapted to the vessel’s hull form, thereby maximizing efficiency and minimizing noise generation. The simple structure and the robust design keeps maintenance requirements to a minimum and ensures it a long service life.
*Features include:
Compact, well proven, strong hub designs
Few components, robust design
Small overhang weight
Accurate stepless hydraulic pitch control
Reduced hydraulic power requirement
Easy to install, delivered as pre-assembled complete system
Under water replacement of blades
