Marine Desktop Magnetic Compass
Technology & Parameters:
| Modei | Vertical | |
| Card Diameter | 165mm | 190mm |
| Graduation | 1° (0~360°) | |
| Direction Error | ≤0.5° | |
| Swing semi-period | >9.3 seconds (20℃,H=30μT) | |
| Friction error | ≤0.1°(20℃,H=30μT) | |
| Semicircular Deviation Correction | >45°(H=30μT) | |
| Quadrant Deviation Correction | >7° (H=30μT) | |
| Heeling Error Correction | ―75μT~+75μT | |
| Operation temperature | -30℃~+60℃ | |
| Illumination | 24V/15W | |
| Overall Dimensions | 585*315*500 | |
| Installation Dimensions | φ325, 4 long hole 5*30 | |
| Net Weight | ~16 | ~16.5 |
