CDKZ-1 manual steering apparatus
Model:
| Model | BMMEENPAP-004 | |||
| Type | CDKZ-1 | |||
| Power | AC380V, 50Hz; 220V, 50Hz; DC24V A: three –phase 380V, ±5% B:220V, 50Hz, ±5% C:DC24V, 3A,+10% ~ -10% | |||
| Steering | manual | |||
| Steering mode | ±40º | |||
| Solenoid valve parameters | DC24V,rated current≤3A | |||
| Alarm range | power failure, overload, phase failure, power failure control, low oil level, oil temperature, oil filter blockage, the pressure difference; and an alarm test function and automatic reset function after silencer; | |||
| No. | Name | Type | Quantity | protect |
| 1 | Main Instrument | CDKZ-C | 1 | IP22 |
| 2 | 1 # pump start box | SC9-K | 1 | |
| 3 | 2 # pump start box | SC10-K | 1 | |
| 4 | Steering gear steering alarm box | CKD-4 | 1 | |
| 5 | Wheel device | CDL-2 | 1 | |
| 6 | Rudder angle transmitter | OD-24ZF | 1 | IP56 |
